Airtac SILF Front Locking Air Cylinder SILF125X480-S
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF125X480-S Front Lock Cylinder Specifications
- Model: SILF125X480-S
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 125mm
- Stroke: 480mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Lock holding force: 12,500N (max at 0.5MPa)
- Cushioning type: Adjustable pneumatic cushion (front/rear)
- Port size: G1/2 (ISO228 standard)
- Piston speed: 50–800mm/s
- Seal material: NBR + polyurethane (high wear resistance)
- Temperature range: -20℃ to 80℃ (standard) / -10℃ to 150℃ (high-temp variant)
- Rod material: Chrome-plated carbon steel (S45C)
- Weight: 15.8kg (excluding accessories)
- Dimensions:
- Length: 830mm (full extension)
- Body width: 158mm (including mounting brackets)
- Height: 165mm (from base to rod centerline)
- Protection rating: IP67 (dust/water resistant)
Heavy-duty locking cylinder with precision position retention capability, featuring dual safety mechanisms: mechanical lock engages automatically at stroke end, while pneumatic locking activates during operation. Requires 5-40μm filtered air with ISO VG32 hydraulic oil mist lubrication (0.8-1.0cm³/min recommended).
- Press machine safety interlock systems
- Automated welding fixture position locking
- Vertical elevator emergency braking
- Die-casting mold clamping mechanisms
- Overhead crane load stabilization
Installation requirements:
Must be mounted horizontally (±3° tolerance). Allow 25mm clearance around lock mechanism for heat dissipation.
Perform lock calibration every 50,000 cycles using M6 adjustment screw (clockwise to increase engagement force).
| Property | Property Value |
|---|---|
| sku | SILF125X480-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 480mm |
| Lock Position | Front Cover with Lock |
