Airtac SILF Front Locking Air Cylinder SILF200X125
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF200X125 Front Lock Cylinder Specifications
- Model: SILF200X125
- Type: Double-acting with mechanical front lock
- Bore size: 200mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Locking force: 15,000N (max at 0.5MPa)
- Port size: G1-1/2 (NPT1-1/2 optional)
- Piston speed: 50–800mm/s
- Seal material: Polyurethane (NBR optional)
- Temperature range: -20℃ to 80℃
- Weight: 38.5kg (excluding accessories)
- Dimensions: 648mm(L) × 230mm(W) × 230mm(H)
- Rod thread: M45×1.5 (external)
- Protection rating: IP54 (standard)
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism. Features triple sealing system with integrated wear sensor ports. The chromium-plated piston rod and anodized aluminum barrel ensure corrosion resistance in humid environments. Requires 5μm filtered air and ISO VG32 hydraulic oil for lubrication (optional oil-free version available).
- Automated forging press position locking
- Vertical lifting systems in automotive assembly
- Mold clamping in injection molding machines
- Overhead crane emergency braking systems
- Precision fixture positioning in CNC machining
Installation note:
Requires minimum 0.3MPa air pressure to disengage lock.
Mounting orientation must be horizontal (±5° tolerance).
Lubricate lock mechanism every 500,000 cycles using specified grease.
| Property | Property Value |
|---|---|
| sku | SILF200X125 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
