Airtac SR Pressure Regulator SR20006LJ1
2、Compact structure with space-saving design for simplified installation;
3、Stable pressure regulation with superior pressure control performance;
4、Available in standard version and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Pressure Regulators , Brand: AIRTAC , Series: SR
AirTAC SR20006LJ1 Precision Pressure Regulator Specifications
- Model: SR20006LJ1
- Type: Precision air pressure regulator with gauge
- Port size: PT1/4 (BSPP thread)
- Pressure range: 0.05–0.85 MPa
- Maximum flow: 3000 NL/min
- Accuracy: ±0.008 MPa
- Operating temperature: -5℃ to 60℃
- Housing material: Aluminum alloy (anodized)
- Diaphragm material: NBR rubber
- Weight: 320g ±5g
- Dimensions: 98mm(H) × 50mm(W) × 45mm(D)
- Pressure gauge: 40mm dial diameter
- Mounting type: Panel mount with lock nut
- Adjustment knob: Anti-slip rubberized grip
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated 40mm pressure gauge enables real-time monitoring, while the zero-lock mechanism prevents accidental setting changes. Designed for systems requiring precise air pressure control with vibration resistance.
- Pneumatic actuator control in assembly lines
- Air tool pressure stabilization
- Packaging machinery tension control
- Laboratory pneumatic instrument calibration
- Medical gas pressure regulation systems
Installation note:
Install downstream of filter/lubricator (FRL) units. For optimal performance,
maintain vertical orientation and bleed residual pressure before adjustment.
Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
| Property | Property Value |
|---|---|
| sku | SR20006LJ1 |
| Port Size | PT1/8 |
