Airtac SR Pressure Regulator SR20008JN
2、Compact structure with space-saving design for simplified installation;
3、Stable pressure regulation with superior pressure control performance;
4、Available in standard version and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Pressure Regulators , Brand: AIRTAC , Series: SR
AirTAC SR20008JN Precision Pressure Regulator Specifications
- Model: SR20008JN
- Type: Precision air pressure regulator with gauge port
- Adjustment range: 0.05–0.9 MPa
- Max inlet pressure: 1.0 MPa
- Port size: PT1/4 (G1/4 optional)
- Flow capacity: 1,500 L/min (ANR) / Cv=1.8 (SMC equivalent)
- Housing material: Aluminum alloy (anodized finish)
- Diaphragm material: NBR rubber
- Operating temperature: -20℃ to 60℃ (no freezing)
- Weight: 450g ±5%
- Dimensions: 80mm(L) × 50mm(W) × 45mm(H)
- Pressure gauge: Built-in 40mm dial (0-1.6MPa scale)
- Locking mechanism: Spring-loaded adjustment knob with lock ring
- Protection rating: IP40 (non-waterproof)
Industrial-grade pressure regulator featuring zero-leakage poppet design and anti-vibration gauge. Optimized for stable downstream pressure maintenance (±0.02MPa fluctuation) in pulsation-prone systems. Includes T-handle for tool-free adjustment and dual bleed vents for safe depressurization.
- Pneumatic cylinder speed control in assembly lines
- Air tool pressure stabilization in automotive workshops
- Packaging machine clamping force regulation
- Laboratory pneumatic instrument calibration
- Textile machinery air pressure balancing
Installation protocol:
Mount vertically with arrow aligned to airflow direction. Always install
downstream of filter/lubricator (FRL unit). Perform initial "soft start"
by rotating knob counterclockwise to minimum pressure before system activation.
| Property | Property Value |
|---|---|
| sku | SR20008JN |
| Port Size | PT1/4 |
