Airtac STWA Slide Table Cylinder STWA10X25S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Slide Cylinder STWA10X25S Technical Details
- Model Series: STWA (Compact Slide Table Cylinder)
- Bore Size: 10mm
- Stroke: 25mm (±0.5mm tolerance)
- Operating Pressure: 0.1-0.9 MPa
- Cushion Type: Adjustable rubber buffer (both ends)
- Mounting Style: Side-mounted base with 4x M4 threaded holes
- Repeat Positioning Accuracy: ±0.01mm
- Operating Temperature: -10℃ to 60℃ (no freeze)
- Port Size: M5x0.8 (Rc1/8 adaptor included)
- Piston Rod Material: Stainless steel SUS304
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Weight: 0.42kg (without accessories)
- Dimensions: 116mm(L) × 40mm(W) × 40mm(H)
Precision linear actuator combining cylinder and slide table functions, featuring dual-guide rod construction for enhanced rigidity. The anodized aluminum body with chrome-plated shafts resists wear in high-cycle applications (up to 2 million cycles). Integrated T-slot allows modular component mounting.
- PCB component insertion machines
- Micro-dispensing systems for adhesives
- Semiconductor wafer handling
- Automated optical inspection (AOI) equipment
- Precision laser cutting positioners
Operation Tip:
Lubricate guide shafts weekly with ISO VG32 hydraulic oil. Avoid lateral
loads exceeding 3N·m. For vertical mounting, use counterbalance valves
to prevent unexpected descent during power loss.
| Property | Property Value |
|---|---|
| sku | STWA10X25S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
