Airtac STWA Slide Table Cylinder STWA10X50S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Series Slide Cylinder STWA10X50S Technical Details
- Model: STWA10X50S
- Type: Compact slide guide cylinder (double rod)
- Bore size: 10mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Mounting style: Horizontal base slot (2x M4 threaded holes)
- Material: Aluminum alloy body, SUS304 guide rod
- Lubrication: Pre-lubricated (ISO VG32 compatible)
- Repeat accuracy: ≤±0.01mm
- Max speed: 500mm/s
- Protection class: IP65 (dust/water jet resistant)
- Accessories: Magnetic switch compatible (D-A93 series)
- Weight: 0.35kg (excluding accessories)
- Dimensions: 126mm(L) × 25mm(W) × 20mm(H)
- Mounting spacing: 20mm center-to-center
High-precision linear actuator with integrated guide rails, featuring zero rotational deflection during operation. The hardened stainless steel shaft and dual bearing design ensure 500km+ service life under rated load. Requires 40μm filtered air with 1-2 drops of oil per 1m³ airflow for optimal performance.
- PCB component insertion machines
- Lens polishing equipment positioning
- Semiconductor wafer handling systems
- Automated optical inspection (AOI) stages
- Precision dosing valve actuation
Installation protocol:
Align guide rail surface within 0.05mm/m flatness tolerance. Use torque-controlled
tightening (0.7-1.2N·m for M4 screws). Perform 50+ low-pressure break-in cycles
(≤0.2MPa) before full-load operation.
| Property | Property Value |
|---|---|
| sku | STWA10X50S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
