Airtac STWA Slide Table Cylinder STWA20X175S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA20X175S Slide Cylinder Specifications
- Model: STWA20X175S
- Type: Guided slide table cylinder (double-acting)
- Bore size: 20mm
- Stroke: 175mm ±0.5mm
- Mounting type: Square flange with precision ground base
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Repeat positioning accuracy: ±0.05mm
- Operating temperature: -10℃ to 70℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston rod material: Hard chrome-plated SUS304
- Seal material: HNBR (high nitrile) with wear-resistant ring
- Lubrication: Pre-lubricated (DOP-free grease)
- Weight: 1.8kg (excluding accessories)
- Dimensions: 290mm(L) × 42mm(W) × 42mm(H) (at full extension)
- Protection rating: IP54 (standard wiper seal)
High-rigidity slide cylinder with integrated linear guide rails, designed for precision linear motion applications. Features dual piston rod configuration for enhanced moment resistance and 4-row ball bearing guides for smooth operation under lateral loads. Includes built-in T-slot mounting grooves (6mm width) for accessory attachment.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Automated vial sorting systems in pharma
- Precision welding jig transporters
- 3D printer head linear actuators
Installation note:
For optimal performance, maintain horizontal mounting (±3° tolerance) and use alignment jigs during setup.
Requires 0.3μm filtered air with dew point -20℃ below ambient. Relubrication interval: 1,000km travel distance.
| Property | Property Value |
|---|---|
| sku | STWA20X175S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 175mm |
