Airtac STWA Slide Table Cylinder STWA25X175S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA25X175S Slide Table Cylinder Specifications
- Model: STWA25X175S
- Type: Dual-axis guided slide cylinder with linear guideway
- Bore size: 25mm
- Stroke: 175mm (±0.5mm accuracy)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable hydraulic buffers (both ends)
- Piston rod material: Hard chrome-plated steel (S45C)
- Body material: Aluminum alloy (A6063-T5)
- Seal material: NBR (Nitrile), optional FKM available
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
- Repeat positioning accuracy: ±0.05mm
- Max lateral load capacity: 90N
- Max moment load: 8.5N·m
- Mounting options: Side-mount, flange, or base plate
- Sensor compatibility: M9/M12 inductive sensors
- Weight: 1.85kg (excluding accessories)
- Dimensions: 250mm(L) × 40mm(W) × 60mm(H)
- Protection rating: IP54 (standard wipers)
Precision-engineered dual-axis cylinder with integrated linear guide rails, designed for high rigidity and smooth linear motion. Features hardened steel guide shafts (HRC60+) and precision ground surfaces for minimal deflection under load. The T-slot mounting surface allows modular component attachment, while the optimized seal geometry reduces breakaway pressure to <0.08MPa.
- CNC machine tool automatic tool changers
- Precision optical component positioning stages
- Automated test equipment (ATE) probe positioning
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
Installation note:
Use alignment jigs during mounting to ensure parallel tolerance <0.1mm/m.
Apply anti-vibration Loctite 243 to mounting screws (2.5N·m torque limit).
Perform 50-100 break-in cycles at 0.3MPa before full-load operation.
| Property | Property Value |
|---|---|
| sku | STWA25X175S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 175mm |
