Airtac STWA Slide Table Cylinder STWA25X25S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA25X25S Slide Cylinder Technical Details
- Model: STWA25X25S
- Type: Compact guided slide cylinder (single rod)
- Bore size: 25mm
- Stroke: 25mm (standard), customizable up to 300mm
- Operation: Single-acting spring return
- Port size: 1/8" NPT (M5x0.8 optional)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Piston speed: 50-700 mm/s
- Ambient temperature: -20℃ to +80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 1.25 kg (with standard stroke)
- Dimensions (L×W×H):
- Body width: 50mm
- Body height: 35mm
- Total length: 130mm (25mm stroke) = stroke + 105mm base length
- Mounting center spacing: 30mm (vertical) × 25mm (horizontal)
- ISO standard: 6432 (mounting dimensions compatible)
- Protection class: IP54 (standard), IP67 optional
Precision linear actuator combining cylinder and slide guide in one unit, featuring dual-axis stabilization for smooth rectilinear motion. The integrated guide rail design eliminates rotational movement, making it ideal for applications requiring precise positional accuracy (±0.1mm repeatability). Factory pre-lubricated with Molykote EM-30L grease for maintenance-free operation.
- PCB board handling robots
- Lens polishing equipment positioning
- Semiconductor wafer transfer systems
- Pharmaceutical blister packaging machines
- Automotive component testing jigs
Installation protocol:
Mount on flat surface with ≤0.1mm/m parallelism tolerance. Use M4×12 mounting screws (6 places)
torqued to 1.2N·m. Lubricate guide rails with ISO VG32 hydraulic oil if operated below -10℃.
| Property | Property Value |
|---|---|
| sku | STWA25X25S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <25 mm> |
