Airtac STWA Slide Table Cylinder STWA25X50S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Series Guided Cylinder STWA25X50S Technical Specifications
- Model: STWA25X50S
- Series: Compact guided cylinder with double rail
- Bore size: Ø25mm
- Stroke: 50mm (±0.5mm tolerance)
- Action type: Double-acting
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Seal material: Polyurethane (NBR seals available on request)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Mounting: Standard base mounting with multiple M4 threaded holes
- Repeat positioning accuracy: ±0.01mm (under no-load condition)
- Max speed: 500mm/s (with cushioning)
- Protection rating: IP54 (standard wipers included)
- Weight: 0.82kg (aluminum body)
- Dimensions: 160mm(L) × 42mm(W) × 42mm(H) (retracted state)
High-rigidity slide cylinder featuring dual linear guide rails for precision linear motion. The STWA25X50S combines 3.5mm thick anodized aluminum housing with chrome-plated piston rod (Ø10mm). Includes magnetic piston for sensor compatibility and adjustable stroke limiter slots. Requires ISO 8573-1 class 3-4-3 compressed air.
- PCB component insertion machines
- Lens polishing equipment positioning
- Semiconductor wafer handling systems
- Pharmaceutical blister packaging lines
- Automated optical inspection (AOI) stages
Maintenance note:
Lubricate with ISO VG32 turbine oil (1-2 drops weekly). Avoid side-load exceeding 15N·m.
For vertical mounting, use counterbalance valves (sold separately).
| Property | Property Value |
|---|---|
| sku | STWA25X50S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <50mm> |
