Airtac STWB Slide Table Cylinder STWB10X100S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB10X100S Specifications
- Model: STWB10X100S
- Bore size: 10mm
- Stroke: 100mm
- Operating pressure: 0.1-0.7 MPa
- Buffer type: Rubber cushion (both ends)
- Mounting style: Side mounting holes with dual guide shafts
- Repeat positioning accuracy: ±0.01mm
- Operating temperature: -10℃ to 60℃
- Lubrication: Pre-lubricated (use ISO VG32 or equivalent)
- Port size: M5x0.8 (Rc1/8 compatible)
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Weight: 0.35kg (excluding accessories)
- Dimensions: 180mm(L) × 42mm(W) × 25mm(H)
- Piston speed: 50-700mm/s (optimal range 100-500mm/s)
- Max lateral load: 0.5N·m
- Accessories: Includes 2x M4x8 mounting screws & alignment pins
High-precision dual-axis slide cylinder with integrated linear guide rails, designed for ultra-stable linear motion in automated systems. Features wear-resistant brass bushings and chrome-plated shafts for smooth operation. Integrated T-slot allows direct mounting of tooling plates. Compatible with optional magnetic sensor (M9x1 thread).
- PCB component insertion machines
- Laser marking positioning stages
- Micro-dispensing systems
- Semiconductor wafer handling
- Optical lens alignment fixtures
Installation note:
Apply anti-vibration washers when mounting on thin panels.
Maintain 0.5mm clearance between stopper and guide shafts during alignment.
Requires periodic lubrication every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | STWB10X100S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 100mm |
