Airtac STWB Slide Table Cylinder STWB16X25S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X25S Slide Table Cylinder Specifications
- Model: STWB16X25S
- Bore size: 16mm
- Stroke: 25mm
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber bumper (both ends)
- Mounting style: Base plate mounting with 4x M4 threaded holes
- Port size: M5x0.8 (dual ports on both ends)
- Piston speed: 50–700 mm/s
- Temperature range: -10℃ to 70℃
- Material: Aluminum alloy barrel, hard chrome-plated piston rod
- Weight: 0.38 kg (without accessories)
- Dimensions: 122mm(L) × 30mm(W) × 28mm(H)
- Protection rating: IP54 (standard wiper seal)
- Repeat positioning accuracy: ±0.1mm
- Max lateral load: 1.5N·m
Precision linear slide cylinder with integrated guide rails, designed for high-accuracy positioning in automated systems. Features dual anti-rotation shafts and low-friction seals for smooth operation. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (0.1-1 drop/minute recommended).
- PCB component insertion machines
- Lens coating automation systems
- Pharmaceutical blister packaging lines
- Microswitch actuation mechanisms
- Semiconductor wafer handling
Installation tip:
Align guide shafts parallel to work surface within 0.05mm/m.
Lubricate through air supply for first 3 months of operation.
Avoid side impact forces exceeding 15N during mounting.
| Property | Property Value |
|---|---|
| sku | STWB16X25S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <25 mm> |
