Airtac STWB Slide Table Cylinder STWB16X50S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X50S Slide Table Cylinder Specifications
- Model: STWB16X50S
- Type: Double-axis guided slide cylinder
- Bore size: Ø16mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting: Standard side mounting holes (M5×0.8 depth 8mm)
- Port size: M5×0.8 (G1/8 adaptor optional)
- Max speed: 500mm/s (with cushioning)
- Repeat positioning accuracy: ±0.1mm
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, hard anodized guide rods
- Seal material: NBR with grease retention grooves
- Protection rating: IP40 (standard), IP57 optional
- Weight: 0.62kg (excluding accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H)
Precision linear actuator combining pneumatic power with mechanical guidance, featuring twin chrome-plated shafts for enhanced moment resistance. Integrated T-slot design allows direct mounting of sensors or tooling plates. Anti-rotation mechanism ensures stable linear motion under side loads up to 2.5N·m.
- PCB board handling robots
- Lens polishing equipment position stages
- Automated screw driving machines
- Precision dispensing systems
- CNC tool changer mechanisms
- 3C product assembly lines
Operation note:
Lubricate guide shafts weekly with ISO VG32 hydraulic oil.
For vertical installations, reduce payload by 30% and
maintain air supply dew point below 3℃ to prevent condensation.
| Property | Property Value |
|---|---|
| sku | STWB16X50S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <50mm> |
