Airtac STWB Slide Table Cylinder STWB16X75S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X75S Slide Table Cylinder Specifications
- Model: STWB16X75S
- Type: Guided slide table cylinder (double-acting)
- Bore size: 16mm
- Stroke: 75mm
- Mounting style: Through-hole base mounting
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Repeat positioning accuracy: ±0.05mm
- Operating temperature: -10℃ to 80℃
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 0.68 kg (complete assembly)
- Dimensions:
- Total length: 164mm (including mounting base)
- Table width: 40mm
- Overall height: 34mm
- Center-to-center guide spacing: 28mm
- Protection rating: IP54 (standard)
Precision linear motion solution combining cylinder thrust with guided stability. Features dual linear ball bearings for smooth movement and high moment resistance. The anodized aluminum table surface allows direct mounting of workpieces. Optimized for applications requiring straight-line accuracy under lateral loads.
- PCB component insertion machines
- Lens positioning in optical inspection systems
- Precision dispensing equipment
- Semiconductor wafer handling
- Automated test probe positioning
Installation tip:
Maintain parallelism within 0.1mm/m between slide table and mating surface.
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Avoid side impact forces exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | STWB16X75S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 75mm |
