Airtac STWB Slide Table Cylinder STWB20X100S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB20X100S Specifications
- Model: STWB20X100S
- Bore size: 20mm
- Stroke: 100mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Side mounting holes (M5x0.8, 4 places)
- Guide rods: 2 chrome-plated steel rods (Ø10mm)
- Repeatability: ±0.05mm
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Seal material: NBR (Nitrile rubber)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
- Protection rating: IP40
- Weight: 1.3kg (excluding accessories)
- Dimensions: 218mm(L) × 52mm(W) × 40mm(H) (at mid-stroke)
High-precision linear motion system combining cylinder and guide mechanism, featuring low-friction operation and dust-resistant design. The dual guide rod configuration ensures exceptional lateral load capacity (15N·m max moment) while maintaining smooth movement. Integrated mounting slots allow direct attachment of tooling plates or sensors.
- Precision positioning in semiconductor handling
- Vertical Z-axis movement in 3D printing systems
- Component insertion in automotive assembly lines
- Optical lens alignment mechanisms
- Multi-axis coordinate measuring machines
Installation tips:
Maintain 0.05mm/m alignment tolerance during mounting.
Use anti-vibration washers when attaching to aluminum frames.
Perform 50-100 no-load cycles before critical operations.
- Max speed: 500mm/s (with cushion adjustment)
- Static friction: ≤2N
- Dynamic friction variation: ≤±0.8N
- Lubrication interval: 1,000km travel distance or 6 months
| Property | Property Value |
|---|---|
| sku | STWB20X100S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
