Airtac STWB Slide Table Cylinder STWB20X150S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB20X150S Technical Details
- Model: STWB20X150S
- Bore size: 20mm
- Stroke: 150mm
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (dual ports)
- Cushion type: Adjustable rubber bumper (both ends)
- Material: Aluminum alloy body, hard anodized slide rail
- Temperature range: -10℃ to 70℃
- Repeat positioning accuracy: ±0.05mm
- Max speed: 500mm/s
- Mounting style: Through-hole base mounting (M5x0.8 threads)
- Weight: 1.35kg ±2%
- Dimensions (L×W×H): 228mm × 34mm × 42mm
- Protection class: IP54 (standard)
- Lubrication: Pre-lubricated (Grease-free operation available)
- Accessory options: Magnetic switch groove (compatible with D-A93/D-C73)
Precision linear actuator combining cylinder and guide mechanism, featuring integrated ball bearings for smooth linear motion. The dual-piston design minimizes lateral play (<0.1mm) during operation. Optimized for vertical/horizontal mounting with optional shock absorbers (ASD series). Requires 5μm filtered air with dew point -25℃ or lower.
- PCB component insertion machines
- Automated screw driving stations
- Lens polishing equipment positioning
- Battery cell stacking mechanisms
- Semiconductor wafer handling systems
Maintenance tip:
Relubricate guide rails every 500km of cumulative travel using ISO VG32 hydraulic oil.
Avoid side load exceeding 15N·m to prevent ball bearing deformation.
| Property | Property Value |
|---|---|
| sku | STWB20X150S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
