Airtac STWB Slide Table Cylinder STWB20X25S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Slide Cylinder STWB20X25S Technical Details
- Model: STWB20X25S
- Series: Precision Linear Guide Slide Cylinder
- Bore size: 20mm
- Stroke: 25mm (±1mm tolerance)
- Max speed: 500mm/s
- Cushion type: Adjustable rubber buffer
- Mounting: Dual-rail linear guide system
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body with chrome-plated piston rod
- Seals: NBR + PU hybrid seals
- Protection rating: IP54 (standard dust/moisture resistance)
- Weight: 1.8kg ±5%
- Dimensions: 200mm(L) × 62mm(W) × 54mm(H)
- Rod end style: Female M5 threaded connection
- Lubrication: Pre-lubed (Grease-packed)
High-precision slide cylinder combining pneumatic actuation with linear guide technology. Features dual-axis stabilization for reduced lateral play (±0.05mm repeat accuracy). Integrated scraping seals prevent particulate ingress in dirty environments. Optimized for vertical/horizontal mounting with anti-vibration mounting holes.
- PCB component insertion machines
- Automated optical inspection (AOI) systems
- Laser marking equipment positioning
- Semiconductor wafer handling
- Pharmaceutical blister packaging lines
Installation guidelines:
Apply supplemental lubrication every 50km of travel. Use alignment jigs during
installation to ensure parallel rail mounting (max 0.1mm/m misalignment tolerance).
Limit side load to ≤15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | STWB20X25S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
