Airtac STWB Slide Table Cylinder STWB25X75S
$219.81
Regular price
$227.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
STWB25X75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Both the slide block and main body support mounting for flexible installation;
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
Installation note:
Ensure mounting surface flatness ≤0.1mm/m. Apply Loctite 243
to mounting screws (torque 3.5N·m). Lubricate guide rails every
500km travel distance using DG-7S grease.
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB25X75S Slide Table Cylinder Specifications
- Model: STWB25X75S
- Type: Guided slide table cylinder (double-acting)
- Bore size: 25mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Mounting style: Horizontal base mounting with 4x M5 threaded holes
- Repeat positioning accuracy: ±0.05mm
- Operating temperature: -10℃ to 70℃
- Piston rod material: Hard chrome-plated steel (S45C)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Port size: M5x0.8 (G1/8 adapter available)
- Lubrication: Pre-lubed (Grease DG-7S)
- Weight: 860g ±2%
- Dimensions: 180mm(L) × 42mm(W) × 37mm(H)
- Guide block load capacity: 7.5N·m max torque
- ISO standard: 15552 compliant
Precision-guided pneumatic slide cylinder with integrated linear guide rails, designed for stable linear motion in multi-axis systems. Features wear-resistant brass guide bushings and anti-rotation mechanism. Requires filtered air (5-40μm) with 1-5% lubricating oil mist (ISO VG32).
Typical Applications:
- PCB component insertion machines
- Automated optical inspection (AOI) positioning stages
- Precision part transfer systems
- Laser marking equipment
- Semiconductor wafer handling
- Pharmaceutical blister packaging
Installation note:
Ensure mounting surface flatness ≤0.1mm/m. Apply Loctite 243
to mounting screws (torque 3.5N·m). Lubricate guide rails every
500km travel distance using DG-7S grease.
| Property | Property Value |
|---|---|
| sku | STWB25X75S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 75mm |
