Airtac STWB Slide Table Cylinder STWB32X125S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB32X125S Slide Table Cylinder Specifications
- Model: STWB32X125S
- Bore size: 32mm
- Stroke: 125mm
- Structure: Dual-guide rail design with integrated linear guides
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber buffers (both ends)
- Mounting style: Horizontal base mounting with multiple bolt patterns
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seals: NBR/Urethane hybrid seals
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
- Weight: 2.8kg ±3%
- Dimensions:
- Length: 312mm (full extended length)
- Width: 60mm (rail center distance)
- Height: 48mm (including mounting base)
- Repeat positioning accuracy: ±0.05mm
- Max lateral load: 150N
- ISO standard: 15552 compliant
The STWB32X125S features a rigid dual-rail structure with precision ground guides, delivering exceptional straightness (≤0.05mm/100mm) for high-precision linear motion. Its integrated design combines cylinder thrust with guided linear motion, eliminating misalignment issues common in modular setups. The hardened aluminum body with IP54-rated dust protection ensures durability in harsh environments.
- PCB component insertion machines
- Automated optical inspection (AOI) positioning stages
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling robots
- 3D printer gantry alignment mechanisms
Installation tip:
For optimal performance, align the slide table within 0.1mm/m parallelism tolerance during mounting.
Use M5x0.8 mounting screws torqued to 3.5N·m. Avoid side-impact loads exceeding 30% of maximum capacity.
| Property | Property Value |
|---|---|
| sku | STWB32X125S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
