This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAU32X10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SU32~50 Standard Cylinder SU32X10
The AirTAC Airtac SU32~50 Standard Cylinder SU32X10 is a double-acting profile-type standard cylinder with a Ø32mm bore and 10mm stroke, 1/8" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAU32X10, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke10 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAU32X10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SU32~50 Standard Cylinder SU32X10
The AirTAC SU32X10 is a discontinued double-acting profile-type cylinder with a 32mm bore and 10mm stroke. Delivering 402N push force at 0.5MPa, it uses an extruded aluminium barrel that is more compact than an ISO 15552 cylinder of the same bore. AirTAC replaced this unit with the SAU32X10, a direct upgrade retaining the exact body, 1/8" port, M10x1.25 rod thread and SC-series mounting.
Because this SKU lacks a magnet, it cannot accept a sensor. The SAU32X10 upgrade also drops the legacy CS1-B/DS1-B switches for modern CMSG/DMSG/EMSG sensors, and introduces the SAUF built-in 4M solenoid valve option the SU line never had.
Airtac SU32~50 Standard Cylinder SU32X10 Technical Specifications
| Model | Airtac SU32~50 Standard Cylinder SU32X10 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAU32X10 |
| Bore size | Ø32 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAU32X10 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAU32X10 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SU32~50 Standard Cylinder SU32X10
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SU32~50 Standard Cylinder SU32X10 Is Used
Small Part Ejection
Uses the 10mm stroke and 402N push force at 0.5MPa to knock lightweight plastic parts out of an injection moulding tool reliably.
Package Diverting
Short 10mm actuation pushes small cartons on a packaging line, fitting easily into tight machinery profiles.
Clamping Jigs
Holds thin workpieces in assembly fixtures where a compact 32mm profile body and minimal stroke are required.
Replacing the Airtac SU32~50 Standard Cylinder SU32X10 with the SAU32X10
To replace the SU32X10, order the SAU32X10 direct equivalent, confirming the 1/8" port, PT thread and SC-series mounting accessories. Since this non-magnetic SKU cannot take a switch, if sensing is needed you must move to an SAU32X10-S and use CMSG/DMSG/EMSG sensors instead of the old CS1-B/DS1-B. For loads needing 563N at 0.7MPa, step up to a 40mm bore; if less force is acceptable, a 32mm is already the smallest profile bore available. Note that a plain cylinder drifts on air loss—the 21mm cushions only decelerate, so use an external rod lock for holding. The SAUF valve-integrated variant is also worth considering for compact actuation.
Replacement checklist
- ✓ Same bore / stroke → SAU32X10
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SU32~50 Standard Cylinder SU32X10 FAQ
Yes, the AirTAC SU32X10 is discontinued. The direct replacement is the SAU32X10. It shares the same 32mm bore, 10mm stroke, 402N force, 1/8" port and SC-series mounting, so it fits the same application without modification.
It delivers 402N push and 345N pull at 0.5MPa, 563N push at 0.7MPa, and a theoretical max of 82kgf at 1.0MPa. This specific SKU has no magnet and cannot take a sensor; the SAU32X10-S replacement uses CMSG/DMSG/EMSG switches.
