Airtac SU32~50 Standard Cylinder SU32X1000
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1000 Standard Cylinder Technical Specifications
- Full Model: SU32X1000
- Series: SU32~50 Standard Series
- Bore Size: 32mm (±0.1mm tolerance)
- Stroke: 1000mm (Max. stroke tolerance: +2.5mm)
- Operation Type: Double-acting
- Working Pressure: 0.15-0.95 MPa
- Medium Temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting Types: Basic type (MF1), Front flange (MP4), Rear foot (MP2)
- Port Size: 1/4" NPT (G1/8 optional)
- Piston Rod Thread: M16x1.5
- Material: Barrel - Aluminum alloy AL6063; Piston Rod - Chrome-plated steel rod (Cr Content≥0.4)
- Seal Material: NBR (Nitrile rubber) with wear-resistant ring
- Protection Class: IP65 (Dust-tight & protected against water jets)
- Weight: 5.8kg (±3%)
- Dimensions (L×W×H): 1100mm × 85mm × 85mm (Stroke extended state)
High-load industrial cylinder designed for long-stroke linear motion applications. Features triple sealing system (rod seal, buffer seal, and wiper seal) with 2,000km minimum service life. The hard-anodized barrel surface (25μm thickness) ensures corrosion resistance in humid environments. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
- Automotive assembly line positioning systems
- Packaging machinery ejection mechanisms
- Plastic injection molding machine clamp units
- Steel coil handling equipment
- Wood processing CNC feed systems
Installation Guidelines:
For strokes >500mm, mandatory use of intermediate support brackets every 300mm.
Lubrication interval: 3 months (ISO VG32 hydraulic oil recommended).
Max lateral load: 120N at full extension.
| Property | Property Value |
|---|---|
| sku | SU32X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
