Airtac SU32~50 Standard Cylinder SU32X1000S
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1000S Standard Cylinder Specifications
- Model: SU32X1000S
- Bore size: 32mm (SU series)
- Stroke: 1000mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Mounting style: Basic type (MF1), optional foot/mounting flange
- Port size: M5x0.8 (G1/8 adapter available)
- Rod end type: External thread M12x1.25
- Cushioning: Adjustable pneumatic cushion
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile) standard, optional FKM
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Weight: 3.8kg ±2% (excluding accessories)
- Dimensions: 1160mm(L) × 48mm(W) × 48mm(H)
- Repeat positioning accuracy: ±0.5mm
- ISO certification: ISO 6431/VDMA 24562
High-precision long-stroke cylinder with corrosion-resistant construction, designed for heavy-duty linear motion applications. Features dual adjustable air cushions for smooth deceleration and integrated magnet slots (D-M9NW switch compatible) for position feedback. Optimal for environments requiring extended reach with minimal deflection.
- Automated palletizing systems
- Plastic injection molding ejectors
- Textile machinery tension control
- Automotive assembly line positioning
- Solar panel cleaning systems
Installation note:
Support rod end when stroke >500mm. Use guide brackets for vertical installations.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃. Maintain 0.3mm minimum
lateral clearance during alignment.
| Property | Property Value |
|---|---|
| sku | SU32X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
