Airtac SU32~50 Standard Cylinder SU32X110SH
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X110SH Standard Cylinder Specifications
- Model: SU32X110SH
- Series: SU32~50 Standard Bore Series
- Bore size: 32mm
- Stroke: 110mm (customizable 25-500mm)
- Operation type: Double-acting
- Working pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with foot mounting holes
- Port thread: G1/8 (ISO228 standard)
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr equivalent ≥0.8μm)
- Seal material: NBR (Nitrile rubber)
- Built-in magnet: Yes (for magnetic switch compatibility)
- Weight: 0.63kg ±2%
- Dimensions:
- Body diameter: 32mm
- Retracted length: 155mm
- Extended length: 265mm
- Mounting base: 25mm × 45mm
- ISO certification: 6431/15552 compliant
High-precision industrial cylinder with integrated cushioning and corrosion-resistant construction. Features low-friction seals and precision honed tube for smooth operation exceeding 3,000km service life. Includes auto-switch ready design with 18mm magnet slot spacing. Requires 40μm filtered air with ISO 8573-1:2010 class 4.4.3 purity.
- Automated assembly line clamping mechanisms
- CNC machine tool fixture actuation
- Material handling transfer systems
- Packaging machine pusher arms
- Textile machinery tension control
Installation protocol:
Lubricate rod end with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum parallel alignment tolerance during mounting.
For vertical installations, use rod-down orientation to prevent seal wear.
| Property | Property Value |
|---|---|
| sku | SU32X110SH |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
