Airtac SU32~50 Standard Cylinder SU32X110SN
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X110SN Standard Cylinder Specifications
- Model: SU32X110SN
- Series: SU32~50 (32mm to 50mm bore sizes)
- Bore diameter: 32mm (±0.1mm tolerance)
- Stroke: 110mm (adjustable cushioning)
- Operating pressure: 0.05~1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushion type: Air cushion with adjustable buffers
- Port size: Rc1/8 (NPT1/8 optional)
- Mounting style: Basic type (MF1) with 4xM5 mounting holes
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel (Cr-Mo)
- Seal material: NBR (nitrile rubber)
- Built-in magnet: Yes (SN suffix indicates magnetic piston)
- Weight: 1.25kg (excluding accessories)
- Dimensions:
- Length: 196mm (full extension)
- Body width: 52mm
- Height: 52mm (mounting base to rod center)
- ISO standard: Compliant with ISO 6432
- Protection class: IP54 (standard sealing)
A high-precision compact cylinder with integrated position sensing capability. Features corrosion-resistant construction and dual-piston seals for leak-proof operation. The nickel-plated end covers and precision honed tube ensure smooth movement cycles exceeding 3,000 km service life. Requires 40μm filtered air with lubrication (non-lube version available).
- Pick-and-place automation systems
- Textile machinery clamping devices
- Semiconductor wafer handling robots
- Medical equipment actuation
- Food packaging line diverters
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use rod-down orientation to prevent seal wear. Lubricate rod weekly in high-cycle
applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | SU32X110SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
