Airtac SU32~50 Standard Cylinder SU32X1150
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1150 Standard Cylinder Specifications
- Model Series: SU32~50 (Standard Cylinder Series)
- Specific Model: SU32X1150
- Bore Size: 32 mm
- Stroke: 1150 mm (Max Stroke for SU32 Series)
- Operating Pressure: 0.15–0.8 MPa
- Cushion Type: Adjustable Air Cushion (Both Ends)
- Mounting Style: Basic Type (Standard) / Optional Foot/Flange Mounts
- Port Size: M5×0.8 (Standard) / NPT1/8 Optional
- Piston Rod Material: Chrome-Plated Stainless Steel (Cr-Mo Steel Core)
- Cylinder Tube: Anodized Aluminum Alloy
- Seal Material: NBR (Nitrile Rubber) / PU Optional
- Temperature Range: -20℃ to 80℃
- Weight: 6.8 kg (With Mounting Brackets)
- Dimensions: 1250mm(L) × 75mm(W) × 80mm(H) (Fully Extended)
- Rod Thread: M12×1.25 (External Thread)
- Protection Rating: IP65 (Dust/Water Jet Resistant)
- Lubrication: Pre-lubricated (Grease-Free Operation)
High-stroke industrial cylinder engineered for heavy-duty linear motion applications. Features dual adjustable air cushions for smooth end-of-stroke deceleration and anti-rotation rod design for precise alignment. The hard chrome-plated rod with integrated scraper seal ensures extended service life in particle-rich environments.
- Automated palletizing systems (box pushing/positioning)
- Plastic injection molding machine ejectors
- Automotive assembly line clamping fixtures
- Large-scale conveyor gate actuators
- Paper processing equipment tension control
Installation note:
For strokes exceeding 1000mm, use intermediate rod supports to prevent buckling.
Align cylinder axis within ±1° angular misalignment tolerance. Lubricate rod weekly
with ISO VG32 hydraulic oil if used in high-cycle (>500k cycles/year) applications.
| Property | Property Value |
|---|---|
| sku | SU32X1150 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 1150 mm |
