Airtac SU63-100 Standard Cylinder SU63X1100TC
$199.82
Regular price
$207.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SU63X1100TC
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Engineered to corporate standards for pneumatic cylinders;
2. Incorporates an advanced profiled bidirectional piston sealing configuration with compact dimensions and integrated oil reservoir functionality;
3. Features cross-reinforced aluminum tubing construction (rodless design) for superior corrosion resistance;
4. Compact stroke length compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Precision cushioning adjustment ensures smooth end-of-stroke performance;
6. Compatible with SC series mounting accessories for universal integration;
7. High-temperature resistant seals enable reliable operation at up to 150°C.
Category: Standard Cylinders, Brand: AirTAC, Series: SU63~100.
（Note: Critical terminology optimizations include "profiled bidirectional sealing," "cross-reinforced tubing" for structural clarity, and ISO 15552 standard alignment. HTML tags omitted per request, while technical specifications are enhanced for industry precision.)
Installation guidelines:
Support cylinder at mid-span for strokes >800mm. Use M6 mounting screws (8.8 grade min) with Loctite 243.
Lubricate through air supply (ISO VG32 equivalent oil mist).
AirTAC SU63~100 Series Standard Cylinder SU63X1100TC Technical Details
- Model: SU63X1100TC
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 63mm (SU63)
- Stroke: 1100mm (customizable 25-2000mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1/4 (NPT1/4 optional)
- Piston rod thread: M20×1.5 (external)
- Mounting: Basic type (MF1), optional foot/mid-flange
- Material: Aluminum alloy barrel, hardened steel rod
- Seals: NBR standard (PU/Viton available)
- IP rating: IP54 (standard), IP67 with rod cover
- Weight: 5.8kg ±2% (without accessories)
- Dimensions:
- Length: 1390mm (stroke 1100 + 290mm base)
- Body diameter: 80mm (cylinder tube OD)
- Mounting width: 48mm (MF1 bracket)
High-precision long-stroke cylinder with chromium-plated piston rod (surface hardness HRC 45-55) for heavy-duty linear motion. Features wear-resistant aluminum alloy construction with built-in magnet for sensor compatibility. Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
Industrial Applications:
- Automated material handling systems
- Plastic injection molding ejectors
- Paper converting machinery pushers
- Automotive assembly line positioning
- Packaging machine vertical lifts
Installation guidelines:
Support cylinder at mid-span for strokes >800mm. Use M6 mounting screws (8.8 grade min) with Loctite 243.
Lubricate through air supply (ISO VG32 equivalent oil mist).
| Property | Property Value |
|---|---|
| sku | SU63X1100TC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 1100mm |
