This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is SAUJ100X120-30STC — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the SAUJ100X120-30STC in place of this model. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X120-30STC
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X120-30STC is a double-acting profile-type standard cylinder with a Ø100mm bore and 120mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the drop-in replacement is the SAUJ100X120-30STC, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke120 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X120-30STC
About the Airtac SUJ Adjustable Cylinder SUJ100X120-30STC
The AirTAC SUJ100X120-30STC is a discontinued double-acting single-rod profile cylinder with an external stop screw that lets you trim the extend stroke by up to 30 mm on-site, yielding a usable 90-120 mm stroke out of the 120 mm nominal maximum. The 100 mm bore delivers 3927 N push and 3681 N pull at 0.5 MPa, rising to 7068 N at 0.9 MPa. It features a 1/2" port, a Ø25 mm rod, and 29 mm adjustable cushions. The TC mount interface uses an SC-series accessory.
This unit is discontinued; the exact drop-in replacement is the SAUJ100X120-30STC, retaining the same force, bore, and FA/LB mounting. The SAUJ upgrades to current CMSG/DMSG/EMSG sensors, whereas this legacy model used CS1-B/DS1-B switches. For sizing, a safe working load is roughly 2356 N (60% of the 0.5 MPa push), translating to a 200 kg vertical lift with a 2:1 margin. Note that the stop screw sets end position but is not a load lock; drift occurs on air loss without an external rod lock.
Airtac SUJ Adjustable Cylinder SUJ100X120-30STC Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X120-30STC |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X120-30STC |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X120-30STC carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X120-30STC produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X120-30STC
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X120-30STC Is Used
Crushing Press Stroke Tuning
Adjusts the extend stop on-site by up to 30 mm to accommodate varying material thicknesses in a compact crushing press without re-engineering the fixture.
Variable Length Diverter
Trims the actuation length on a packaging conveyor diverter gate to handle different carton depths dynamically on the factory floor.
Adjustable End Stop Pusher
Sets a precise mechanical end position for a heavy warehouse pusher that must adapt to multiple pallet sizes while relying on the 100 mm bore force.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X120-30STC with the SAUJ100X120-30STC
To replace the discontinued SUJ100X120-30STC, specify the SAUJ100X120-30STC drop-in. It matches the 100 mm bore, 120 mm nominal stroke, 1/2" port, and TC/FA/LB SC-series mounting. When sizing both ways, the neighboring 80 mm bore yields 2513 N push at 0.5 MPa, while this 100 mm bore provides 3927 N at 0.5 MPa or 5497 N at 0.7 MPa. Choose the 30 mm adjust window if your mechanism requires field-tuning the extend stroke down to 90 mm; for fixed 120 mm travel, a standard SAU cylinder suffices. Because this model has the -S magnet, upgrade your position sensing from legacy CS1-B/DS1-B to current CMSG/DMSG/EMSG switches. For strokes of 300 mm or longer, verify side-load limits to prevent guide wear.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X120-30STC
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X120-30STC FAQ
Yes, the AirTAC SUJ100X120-30STC is discontinued. The exact drop-in replacement is the SAUJ100X120-30STC, which matches the 100 mm bore, 120 mm stroke, 1/2" port, and TC/FA/LB SC-series mounting. You must upgrade your position sensors from the legacy CS1-B/DS1-B switches to the current CMSG/DMSG/EMSG series.
The 100 mm bore provides 3927 N push and 3681 N pull at 0.5 MPa, 5497 N push at 0.7 MPa, and 7068 N push at 0.9 MPa, with a theoretical max of 801 kgf at 1.0 MPa. The external stop screw provides a 30 mm adjust window, allowing you to shorten the 120 mm nominal extend stroke down to 90 mm on-site. This stop sets the end position but is not a load lock.
