Airtac SULB Lock Cylinder SULB100X100-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB100X100-S Locking Cylinder Technical Details
- Model: SULB100X100-S
- Type: Double-acting pneumatic cylinder with mechanical lock
- Bore size: Ø100mm
- Stroke: 100mm (customizable 50-500mm)
- Operating pressure: 0.2–1.0 MPa
- Locking mechanism: Pneumatic piston lock with spring assist
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (NPT1/2 optional)
- Cushioning: Adjustable air cushion both ends
- Mounting: Standard ISO 15552 foot & flange
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Protection rating: IP67 (dust/water resistant)
- Weight: 8.5kg ±5% (without accessories)
- Dimensions: 300mm(L) × 150mm(W) × 150mm(H)
Heavy-duty locking cylinder featuring dual safety mechanisms - pneumatic holding force (up to 785N at 0.6MPa) and mechanical position lock. Integrated shock absorption and corrosion-resistant construction enables reliable operation in high-vibration environments. Requires 5μm filtered dry air.
- Press machine safety interlock systems
- Automated welding fixture position retention
- Elevator emergency braking mechanisms
- Robotic arm vertical axis stabilization
- Foundry equipment mold clamping
Installation protocol:
Align cylinder within 0.2mm perpendicular tolerance during mounting.
Perform weekly lubrication via Z2 grease nipple. Locking function requires
separate 0.3-0.6MPa control air supply.
| Property | Property Value |
|---|---|
| sku | SULB100X100-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Lock Position | Rear Cover with Lock Type |
