Airtac SULB Lock Cylinder SULB40X40
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB40X40 Locking Cylinder Technical Specifications
- Model: SULB40X40 Series
- Bore size: 40mm (ISO standard)
- Stroke: Customizable 25-500mm (standard stroke 40mm as default)
- Operating pressure: 0.1-0.9 MPa
- Locking force: 1,250N max @ 0.5MPa
- Piston speed: 50-800 mm/s
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Lock mechanism: Spring-assisted mechanical brake
- Rod end: Male thread M16×1.5
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Body material: Anodized aluminum alloy
- Weight: 1.65kg (base model with 40mm stroke)
- Dimensions (L×W×H): 212mm × 56mm × 56mm (40mm stroke version)
- Protection class: IP54 (standard), IP67 optional
- Mounting types: MF1/MF2 flange, foot-mounted, or rear pivot
Heavy-duty locking cylinder with integrated fail-safe brake mechanism, featuring dual-piston locking design for zero drift under load. The hardened chromium piston rod and wear-resistant guide rings ensure 5,000km+ service life. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Vertical press brake tool positioning systems
- Automated welding fixture hold-down clamps
- CNC rotary table indexer locking
- Overhead conveyor emergency stop stations
- Die-casting machine core pull safety locks
Installation guidelines:
Mount in fixed alignment within ±0.2° angular tolerance. Apply 80% of rated pressure during brake adjustment.
Perform weekly manual brake release tests if idle for extended periods. Avoid side-load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SULB40X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <40mm> |
| Lock Position | Rear Cover with Lock Type |
