Airtac SULB Lock Cylinder SULB80X175
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB80X175 Locking Cylinder Specifications
- Model: SULB80X175
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 80 mm
- Stroke: 175 mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Locking force: 2,500 N (at 0.5 MPa)
- Mounting style: ISO 15552 standard (front/rear flange & foot mounting)
- Port size: G1/2 (BSPP thread)
- Seal material: NBR (nitrile butadiene rubber)
- Protection rating: IP65 (standard rod wiper)
- Weight: 5.8 kg (with standard accessories)
- Dimensions: 350mm(L) × 100mm(W) × 100mm(H) (extended length)
- Rod thread: M20×1.5 (external)
- Lock release pressure: 0.15 MPa (minimum)
- Repeat positioning accuracy: ±0.5 mm
Heavy-duty locking cylinder featuring fail-safe mechanical brake system activated by spring force and released pneumatically. The anodized aluminum construction with chrome-plated piston rod ensures corrosion resistance in harsh environments. Integrated magnetic sensor slots (non-inductive type) enable position feedback when used with compatible sensors.
- Vertical load holding in automated material handling systems
- Emergency stop positioning in press machinery
- Precision fixturing in CNC machining centers
- Overhead safety locking in automotive assembly lines
- Stage equipment positioning in theatrical systems
Installation notes:
- Requires clean, lubricated air (ISO 8573-1:2010 Class 3-4-3)
- Lock engagement occurs automatically at power loss - ensure mechanical stops are installed for overload protection
- Allow 50mm clearance around cylinder body for heat dissipation during continuous operation
- Lubricate locking mechanism every 5,000 cycles using ISO VG32 hydraulic oil
| Property | Property Value |
|---|---|
| sku | SULB80X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 175mm |
| Lock Position | Rear Cover with Lock Type |
