Airtac SULB Lock Cylinder SULB80X270-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB80X270-S Locking Cylinder Specifications
- Model: SULB80X270-S
- Type: Double-acting with mechanical locking (rear side)
- Bore size: 80mm
- Stroke: 270mm
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Spring-loaded mechanical brake
- Mounting style: Standard front flange (ISO 15552 compatible)
- Port size: PT1/2 (G1/2 optional)
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Weight: ~4.8kg (excluding accessories)
- Dimensions: 370mm(L) × 80mm(W) × 80mm(H) (total extended length)
- Rod thread: M20×1.5
- Protection rating: IP65 (standard wiper design)
- Max locking force: 2,500N (at 0.5MPa)
Industrial-grade locking cylinder featuring fail-safe mechanical brake engagement during power/pressure loss. Precision-ground rod with chrome plating ensures smooth operation. Integrated shock absorbers prevent end-position impact damage. Requires 15-30μm filtered air and ISO VG32 hydraulic oil lubrication (optional oil-free version available).
- Vertical load holding in automated assembly lines
- Safety position locking in material handling systems
- Press machine tooling position retention
- Automotive welding fixture stabilization
- Injection molding machine core pulling mechanisms
Installation note:
Locking mechanism requires 0.3MPa minimum working pressure for reliable disengagement.
Maintain 0.5mm minimum clearance between brake unit and mounting surface.
Lubricate guide shafts monthly under continuous operation.
| Property | Property Value |
|---|---|
| sku | SULB80X270-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 270mm |
| Lock Position | Rear Cover with Lock Type |
