Airtac SULB Lock Cylinder SULB80X350
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB80X350 Locking Cylinder Specifications
- Model: SULB80X350
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø80 mm
- Stroke: 350 mm (customizable up to 500mm)
- Operating pressure: 0.1–1.0 MPa
- Locking force: 2,800 N (at 0.5 MPa)
- Piston speed: 50–800 mm/s
- Port size: G3/8 (NPT1/2 optional)
- Lock mechanism: Spring-engaged wedge system
- Cushioning: Adjustable air cushion + rubber bumper
- Seal material: HNBR + PTFE composite
- Temperature range: -20℃ to 120℃
- Weight: 6.8 kg (dry, without accessories)
- Dimensions: 576mm(L) × 105mm(W) × 105mm(H)
- Rod thread: M20×1.5 (ISO standard)
- Protection rating: IP67 (wipers included)
Heavy-duty locking cylinder featuring fail-safe mechanical position retention. The dual-stage locking mechanism combines spring force with pneumatic pressure for zero drift during power loss. Precision ground rod (hard chrome plated) ensures ≤0.01mm repeatability. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in material handling systems
- Precision fixturing for CNC machining centers
- Safety brakes in elevator test rigs
- Overhead clamping in automotive welding stations
Installation requirements:
Mounting orientation must be horizontal (±5° tolerance). Allow minimum 50mm
clearance around lock housing for thermal expansion. Perform lock engagement
test every 10,000 cycles using built-in manual override port (M5×0.8).
| Property | Property Value |
|---|---|
| sku | SULB80X350 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 350mm |
| Lock Position | Rear Cover with Lock Type |
