Airtac SULB Lock Cylinder SULB80X400-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB80X400-S Locking Cylinder Specifications
- Model: SULB80X400-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø80 mm
- Stroke: 400 mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥1500 N (at 0.5 MPa)
- Cushioning: Adjustable elastic cushion (both ends)
- Ambient temperature: -20℃ to 80℃
- Port size: G1/2 (ISO228 standard)
- Rod thread: M30×1.5
- Material: Aluminum alloy barrel, hardened chromium piston rod
- Seal type: HNBR seals (standard) / FKM optional
- Weight: 12.5 kg ±3%
- Dimensions: 575mm(L) × 105mm(W) × 105mm(H) (retracted state)
- Lock release pressure: ≤0.15 MPa
- Protection class: IP54 (standard)
Heavy-duty locking cylinder featuring dual-position mechanical brake mechanism for fail-safe load holding. The integrated wedge-block locking system engages automatically during pressure loss, with precision ground guide rods ensuring <1mm position drift. Requires ISO VG32 hydraulic oil lubrication (non-lubricated version available).
- Vertical load suspension in automated assembly lines
- Emergency position locking in injection molding machines
- Overhead material handling systems
- Precision fixturing for CNC machining centers
- Safety brakes in elevator test rigs
Installation note:
Locking mechanism requires manual release via auxiliary port during maintenance.
Maintain 0.3mm minimum alignment tolerance between cylinder axis and load direction.
Recommended 500-hour lubrication interval for continuous operation.
| Property | Property Value |
|---|---|
| sku | SULB80X400-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <400mm> |
| Lock Position | Rear Cover with Lock Type |
