Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S
The AirTAC Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S is a genuine double-acting GUIDED compact (JIS) cylinder — a Ø16mm bore, 30mm stroke and two guide rods with a fixing plate. The twin guides hold the platform non-rotating to within ±0.2° and carry lateral load a plain compact rod cannot, so it drives and guides a load in one unit.
- BoreØ16 mm
- Stroke30 mm
- Port sizeM5×0.8
- Acting typeDouble acting, guided
- Non-rotating±0.2°
- CushionBumper (both ends)
About the Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S
This double-acting JIS compact unit combines a standard ACQ body with two stainless guide rods and a fixing plate. It drives and guides your load simultaneously, eliminating the need for a separate linear rail. The twin rods ensure non-rotating accuracy of ±0.2° for this 16mm bore.
Thrust matches a conventional ACQ, meaning the guides add stiffness rather than extra power. You get 100.5N push and 75.4N pull at 0.5MPa. The integrated -S magnet works with reed or solid-state switches, and fixed TPU bumpers absorb impact energy at stroke ends.
Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S Technical Specifications
| Model | Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S |
|---|---|
| Series | TACQ JIS guided compact cylinder |
| Bore size | Ø16 mm |
| Stroke | 30 mm |
| Acting type | Double acting, guided (non-rotating) |
| Non-rotating tolerance | ±0.2° |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Max standard stroke | Up to 30 mm |
Specifications follow the official AirTAC TACQ datasheet. Two guide rods carry lateral load and hold rotation to ±0.2°; do not apply reverse torque beyond the datasheet limit. Confirm against the product label before installation.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 75 N |
| 0.7 MPa | 141 N | — |
| Max (@1.0 MPa) | 21 kgf | |
Drive force equals a standard ACQ of the same bore — the guide rods add stiffness, not thrust. Keep moving mass and speed within the datasheet chart (rated at 0.5 MPa).
Model Code: Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S
| TACQ | JIS compact cylinder WITH guider (non-rotating). |
|---|---|
| 16 | Bore size in mm. |
| ×30 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| thread | Blank = PT; G or NPT available. |
The guide plate replaces a separate rod-thread option. Related: ACQ (plain single rod), ACQD (double rod), ACQJ (adjustable stroke).
Where the Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S Is Used
PCB Pick-and-Place
Serves as a small pick-and-place head where the ±0.2° non-rotating tolerance keeps delicate vacuum grippers perfectly aligned during electronic board handling.
Sensor Slide
Positions a camera or inspection sensor vertically, relying on the twin guide rods to resist lateral deflection without needing an external linear guide.
Pallet Stopper Gate
Functions as a compact stopper gate on a light conveyor line, using the fixing plate to block product flow while enduring minor side impacts.
Is the Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S the Right Cylinder?
When sizing, stepping down to the 12mm bore yields 56.5N push, while moving up to the 20mm bore provides 157.1N at 0.5MPa. Choose a plain ACQ if your load is already externally guided and requires no anti-rotation. Confirm your ordering code details: 16mm bore, 30mm stroke (the maximum standard for this size), S magnet, and PT threads. Always verify the lateral load and reverse torque limits for your specific stroke from the datasheet, as these decrease with extended length.
Quick checklist
- ✓ Lateral load / non-rotation needed?
- ✓ Moving mass and speed within chart
- ✓ Drive force at your pressure
- ✓ Magnet (S) for sensors?
- ✓ No reverse torque on the guide rods
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Do not apply reverse torque above the datasheet limit.
- check Apply external force concentric with the rod.
- check Keep mass × speed within the performance chart.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACQ Guided Rod Ultra-Thin Cylinder TACQ16X30S FAQ
At 0.5MPa it provides 100.5N push and 75.4N pull, reaching 140.8N push at 0.7MPa, with a maximum push of 21kgf at 1.0MPa. The two guide rods maintain a non-rotating tolerance of ±0.2°. The maximum standard stroke for this 16mm bore is 30mm.
The twin rods support lateral loads that a plain compact rod cannot, but maximum allowable reverse torque decreases as stroke increases—consult the datasheet to confirm exact values. It does not hold load on air loss; use an external rod lock for fail-safe holding, and apply external force concentric with the rod.
