Airtac TCL Triple Axis Cylinder TCL16X10-S
$86.55
Regular price
$94.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCL16X10-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TCL Series Three-Rod Cylinder (AirTAC)
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
Installation guidelines:
Maintain 0.05mm maximum parallel misalignment between cylinder axis and load.
Use flexible couplings for Z-axis mounting. Lubricate guide rods monthly with
ISO VG32 hydraulic oil in continuous operation environments.
Critical note:
Avoid side load exceeding 15N. For vertical installations,
always incorporate mechanical locking or brake unit to prevent
unintended movement during power loss.
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
AirTAC TCL16X10-S Triple Axis Cylinder Technical Details
- Model Code: TCL16X10-S
- Type: ISO 15552 compliant triple-axis pneumatic cylinder
- Bore size: 16mm
- Stroke: 10mm (Standard) with ±0.5mm tolerance
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (cushioned)
- Ambient temperature: -20℃ to 80℃
- Port thread: M5×0.8 (G1/8 adaptor included)
- Rod material: Hard chrome-plated SUS304
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Cushioning: Adjustable air cushion (both ends)
- Repeat positioning accuracy: ±0.1mm
- Weight: 620g ±3% (without accessories)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H) (at retracted position)
- Mounting: Standard ISO 15552 mounting grooves
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (Grease-free operation available)
Precision triple-axis cylinder with integrated guide mechanism, featuring dual-axis guide rods flanking the main piston. The TCL series incorporates anti-rotation design for stable multi-directional force transmission. Requires 5μm filtered compressed air with 1-10 mg/m³ oil mist content (ISO 8573-1 class 3).
Industrial Applications:
- Semiconductor wafer handling robots
- PCB optical inspection equipment positioning
- Multi-axis dispensing systems
- Precision alignment mechanisms in display manufacturing
- Automated test equipment (ATE) component actuation
Installation guidelines:
Maintain 0.05mm maximum parallel misalignment between cylinder axis and load.
Use flexible couplings for Z-axis mounting. Lubricate guide rods monthly with
ISO VG32 hydraulic oil in continuous operation environments.
Critical note:
Avoid side load exceeding 15N. For vertical installations,
always incorporate mechanical locking or brake unit to prevent
unintended movement during power loss.
| Property | Property Value |
|---|---|
| sku | TCL16X10-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
| Bearing Code | Linear Bearing |
