Airtac TCL Triple Axis Cylinder TCL16X100-S
$123.26
Regular price
$130.76
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCL16X100-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TCL Series Three-Rod Cylinder (AirTAC)
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
Installation note:
Align all axes within 0.2mm/m parallelism tolerance. Use flexible couplings
when connecting to rigid structures. Pre-lubricate ports with 1-2 drops of
pneumatic oil before initial operation.
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
AirTAC TCL16X100-S Triple Axis Cylinder Specifications
- Model: TCL16X100-S
- Type: Triple-axis compact guided cylinder (X-Y-Z motion)
- Bore size: Ø16mm
- Stroke: 100mm (standard), customizable up to 300mm
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 31.4N at 0.6MPa
- Piston speed: 50–700mm/s
- Mounting type: Front flange with 4×M5 threaded holes
- Cushioning: Adjustable rubber buffers on all axes
- Repeat accuracy: ±0.1mm
- Seal material: Polyurethane (PU) with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Weight: 1.2kg (with standard accessories)
- Dimensions: 180mm(L) × 62mm(W) × 62mm(H) (at mid-stroke)
- Port size: M5×0.8 (dual ports per axis)
- Protection rating: IP54 (dust protected & water splashed)
Precision triple-axis pneumatic actuator with integrated guide rails, designed for multi-directional positioning in confined spaces. Features chrome-plated piston rods with anti-rotation mechanism and built-in magnet for sensor mounting. Requires ISO VG32 or equivalent lubrication oil for extended service life.
Typical Applications:
- PCB component insertion machines
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling systems
- Pharmaceutical blister packaging lines
- Robotic end-effector positioning
Installation note:
Align all axes within 0.2mm/m parallelism tolerance. Use flexible couplings
when connecting to rigid structures. Pre-lubricate ports with 1-2 drops of
pneumatic oil before initial operation.
| Property | Property Value |
|---|---|
| sku | TCL16X100-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 100mm |
| Bearing Code | Linear Bearing |
