TCL Series Three-Rod Cylinder (AirTAC)
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
Installation guidelines:
Mount on machined flat surface (flatness ≤0.1mm/mm).
Apply lateral load ≤5N perpendicular to rod.
For vertical installations, use counterbalance valves.
Lubricate guide shafts every 500km travel distance.
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
AirTAC TCL16X200-S Triple Axis Cylinder Technical Details
- Model: TCL16X200-S
- Type: Triple-axis guided cylinder (square body)
- Bore size: 16mm
- Stroke: 200mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Front flange with precision alignment grooves
- Port size: M5x0.8 (dual ports at both ends)
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Body material: Anodized aluminum alloy (black finish)
- Seal material: Heat-resistant NBR
- Weight: 1.85kg (without accessories)
- Dimensions: 230mm(L) × 50mm(W) × 50mm(H)
- Protection rating: IP40 (dust protected)
- Lubrication: Pre-lubricated (ISO VG32 compatible)
Precision-engineered triple-axis cylinder combining linear motion with guided stability, featuring dual hardened steel shafts (Ø8mm) and anti-rotation mechanism. The TCL series delivers ±0.1mm repeat positioning accuracy under 0.5MPa, with integrated wear-resistant brass bushings reducing lateral play. Requires filtered air (5-40μm) with max piston speed 700mm/s.
Industrial Applications:
- PCB handling robots - prevents component misalignment
- Laser cutting platforms - maintains nozzle perpendicularity
- Semiconductor wafer transfer systems
- Automated optical inspection (AOI) equipment
- Precision clamping fixtures for CNC machining
Installation guidelines:
Mount on machined flat surface (flatness ≤0.1mm/mm).
Apply lateral load ≤5N perpendicular to rod.
For vertical installations, use counterbalance valves.
Lubricate guide shafts every 500km travel distance.
| Property | Property Value |
|---|---|
| sku | TCL16X200-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <200mm> |
| Bearing Code | Linear Bearing |
