Airtac TCL Triple Axis Cylinder TCL63X175-S
1. Compliant with JIS industrial standards;
2. Dual precision guide rods manufactured from bearing steel, guided by either linear ball bearings or bronze sliding bearings for enhanced performance:
★ Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity and low friction movement.
★ Bronze sliding bearings: Superior radial load resistance with 2X higher lateral impact resistance and enhanced torsional stiffness compared to standard brake cylinders, optimal for braking operations.
3. Integrated design combines driving unit and guiding mechanism within single body structure, minimizing spatial requirements while offering selectable port positions for flexible installation;
4. Precision positioning through dual locating holes on base face, rear face and mounting plate (refer to PA and XX reference holes in outline drawing), with optional high-precision alignment solutions;
5. Four magnetic sensor grooves enable multiple proximity switch configurations;
6. Versatile multi-orientation mounting options through innovative body design.
Category: Guided Three-Rod Cylinder | Brand: AirTAC | Series: TCL
AirTAC TCL Series 3-Axis Cylinder TCL63X175-S Technical Specifications
- Model: TCL63X175-S
- Type: Triple-axis guided cylinder (X/Y/Z linear motion)
- Bore size: Ø63mm
- Stroke: 175mm (adjustable stroke version available)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Cushion type: Rubber buffer + adjustable hydraulic absorber
- Mounting style: Rectangular base with M8 threaded holes (4-point fixation)
- Port size: G3/8 (NPT1/4 optional)
- Ambient temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 recommended for maintenance)
- Repeat accuracy: ±0.1mm
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized surface)
- Weight: 6.8kg (excluding accessories)
- Dimensions: 370mm(L) × 135mm(W) × 135mm(H)
High-precision triple-axis pneumatic cylinder with integrated linear guides, designed for multi-directional positioning tasks requiring exceptional stability. Features dual sealing system (NBR + PU) for leak prevention and maintenance-free operation. The T-shaped guide rail structure ensures synchronized movement across axes with minimal deflection (≤0.05mm/m). Includes magnetic piston for position sensing compatibility.
- CNC machine tool automatic tool changers
- Precision assembly of electronic components
- Automated material handling in cleanroom environments
- 3D inspection equipment positioning systems
- Robotic end-effector manipulation
Installation guidelines:
Maintain 0.02mm/m alignment tolerance during mounting. Use flexible couplings when connecting to driven components.
Perform initial lubrication cycle (5-10 full strokes) before load operation. Replace guide lubricant every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | TCL63X175-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 63mm |
| Stroke | 175mm |
| Bearing Code | Linear Bearing |
