Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ100X200-100S
$673.22
Regular price
$680.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ100X200-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation notes:
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ100X200-100S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ100X200-100S
- Type: Triple-axis adjustable pneumatic cylinder (rod-type)
- Bore diameter: 100mm
- Stroke: 200mm
- Adjustment stroke: 100mm (axial direction)
- Mounting style: Front flange (MF1) with multi-position mounting holes
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + external shock absorber
- Port size: G3/8 (standard) / optional NPT1/2
- Rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Anodized aluminum alloy
- Seals: NBR (standard) / optional FKM for high temp
- Weight: ~6.8kg (including mounting accessories)
- Dimensions: 320mm(L) × 140mm(W) × 140mm(H)
- Protection rating: IP40 (dust protected)
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil if needed)
A heavy-duty multi-axis positioning cylinder featuring 360° adjustable mounting angles and precision ground rods (±0.01mm concentricity). The triple-axis design allows X/Y/Z directional force application with integrated locknuts for position retention. Optimized for vibration damping with dual-stage buffering system.
Typical Applications:
- Multi-station rotary indexing tables
- Printing press roller adjustment systems
- Automated welding positioners
- Palletizing robot end-effector alignment
- Semiconductor wafer handling equipment
Installation notes:
- Use torque wrench (35-40N·m) for mounting bracket installation
- Maintain 0.5mm minimum clearance between adjustment bolts
- Apply thread-locking compound to position set screws
- Align within 0.2mm perpendicularity during assembly
Operation Guidelines:
- Maximum side load: ≤15% of thrust rating
- Re-lubrication interval: 500km stroke distance or 6 months
- Air filtration: 5μm absolute with auto-drain filter
- Allow 2-minute run-in period after installation
| Property | Property Value |
|---|---|
| sku | TCLJ100X200-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-400mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
