Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X100-20S
$129.57
Regular price
$137.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X100-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Apply thread-locking compound (medium strength) to adjustment nuts during final calibration.
Maximum lateral load capacity: 15N at full extension. For vertical mounting,
use model with magnetic piston (TCLJ12X100-20S/M).
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X100-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X100-20S
- Type: 3-axis adjustable profile cylinder with multi-position locking
- Bore size: Ø12mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Adjustment mechanism: Precision trapezoidal thread + dual locking nuts
- Mounting type: Side-mount with 4x M4 threaded holes (ISO 6432 standard)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (both ends)
- Material: Aluminum alloy body, CRCC steel rod, NBR seals
- Weight: 0.68kg ±2%
- Dimensions (L×W×H): 202mm × 50mm × 50mm (full extension)
- Rod thread: M6×1.0 at both ends
- Protection rating: IP54 (standard), IP67 (optional wiper kit)
- Lubrication: Pre-lubricated (Grease-free operation available)
High-precision multi-axis positioning cylinder featuring 360° rotatable mounting surfaces and ±5° angular adjustment capability. The TCLJ series employs a unique triple-axis alignment system with graduated scale markings (1mm increments) for repeatable positioning. Includes anti-rotation mechanism for stable vertical applications.
Typical Applications:
- PCB assembly positioning fixtures
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling systems
- Robotic end-effector alignment
- Precision jig calibration devices
Installation note:
Apply thread-locking compound (medium strength) to adjustment nuts during final calibration.
Maximum lateral load capacity: 15N at full extension. For vertical mounting,
use model with magnetic piston (TCLJ12X100-20S/M).
Maintenance Cycle:
- Relubricate every 500km stroke travel (20℃ environment)
- Inspect locking nuts torque (0.8-1.2N·m) monthly
- Replace rod wiper seal after 1 million cycles
| Property | Property Value |
|---|---|
| sku | TCLJ12X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 100mm |
