Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X100-40S
$129.57
Regular price
$137.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X100-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation tip:
Use alignment pins during mounting to ensure parallel axis movement.
Apply silicone-free grease to adjustment screws quarterly. Maximum
lateral load ≤15N. For vertical installations, add 20% safety factor
to force calculations.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X100-40S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X100-40S
- Type: 3-axis adjustable compact cylinder (ISO 6432 compliant)
- Bore size: 12mm
- Stroke: 100mm (±1mm adjustment range)
- Operating pressure: 0.05–0.9 MPa
- Medium: Clean air (lubricated or non-lubricated)
- Temperature range: -10℃ to 70℃ (with NBR seals)
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Side mounting with M4 threaded holes (4x)
- Port size: M5×0.8 (Rc1/8 adaptor optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 0.65kg (excluding accessories)
- Dimensions (L×W×H): 188mm × 40mm × 40mm (at neutral position)
- Repeat accuracy: ±0.2mm
- Max theoretical force: 76N @0.5MPa
- Protection rating: IP54 (standard), IP67 (optional w/wiper)
Modular 3-axis cylinder with micrometer-style fine adjustment (±1mm) on X/Y/Z axes. Features dual anti-rotation guides for precision alignment and overload protection. The anodized body resists chemical corrosion in industrial environments. Includes built-in shock absorbers and auto-lubrication grooves.
Typical Applications:
- Precision jig positioning in CNC machining centers
- 3D vision inspection equipment alignment
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Multi-axis automated testing fixtures
Installation tip:
Use alignment pins during mounting to ensure parallel axis movement.
Apply silicone-free grease to adjustment screws quarterly. Maximum
lateral load ≤15N. For vertical installations, add 20% safety factor
to force calculations.
| Property | Property Value |
|---|---|
| sku | TCLJ12X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 100mm |
