Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X30-10S
$102.79
Regular price
$110.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X30-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation tip:
Apply thread-locking compound to adjustment screws after alignment.
Use 0.5Nm torque for M4 mounting bolts to prevent frame deformation.
Requires weekly lubrication (VG32 oil recommended) for maintenance-free models.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X30-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X30-10S
- Type: 3-axis adjustable compact cylinder (X/Y/Z independent adjustment)
- Bore size: 12mm
- Stroke: 30mm
- Operating pressure: 0.05–0.9 MPa
- Medium: Clean air (lubricated or non-lubricated)
- Temperature range: -10℃ to 60℃
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: Standard M4 threaded holes (4 mounting points)
- Port size: M5 (Rc1/8 optional)
- Material: Aluminum alloy body, chrome-plated piston rod
- Adjustment range: ±2mm per axis (total 4mm compensation)
- Repeat positioning accuracy: ±0.05mm
- Max speed: 500mm/s
- Weight: 0.38kg
- Dimensions: 112mm(L) × 48mm(W) × 48mm(H)
- Protection rating: IP54
- Compliance: ISO 6432, RoHS
Precision alignment cylinder with unique triaxial micro-adjustment mechanism (±2mm per axis), featuring tool-free locking screws for positional fine-tuning. Integrated shock absorption and anti-rotation design ensures stable operation in high-cycle applications. Compatible with vacuum pads and custom tooling attachments.
Typical Applications:
- Robotic end-effector positioning systems
- Optical component alignment in laser machining
- PCB board fixture adjustment stations
- Precision assembly of micro-mechanical components
- 3D sensor mounting platforms
Installation tip:
Apply thread-locking compound to adjustment screws after alignment.
Use 0.5Nm torque for M4 mounting bolts to prevent frame deformation.
Requires weekly lubrication (VG32 oil recommended) for maintenance-free models.
| Property | Property Value |
|---|---|
| sku | TCLJ12X30-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 30mm |
