Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X40-20S
$117.47
Regular price
$124.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X40-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation Best Practices:
Always perform axis alignment before locking mechanism engagement.
Use 0.5-1.0Nm torque for adjustment screws. Lubricate guide shafts monthly
with light machine oil (ISO VG15-32). Avoid side-load exceeding 5N.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X40-20S 3-Axis Adjustable Cylinder Specifications
- Model Code Breakdown: TCLJ | 12 (Bore) | X40 (Stroke) | -20 (Accessory Code) | S (Cushion Type)
- Bore Size: 12mm (Precision honed cylinder tube)
- Stroke: 40mm (±5mm adjustable via external screws)
- Operating Pressure: 0.15-0.8 MPa (1.5-8 bar)
- Temperature Range: -20℃ to 80℃ (NBR seals)/li>
- Mounting Styles: Side mounting, front/rear flange options
- Port Size: M5x0.8 (Dual ports for multi-direction control)
- Cushioning: Adjustable pneumatic cushion at both ends
- Rod Thread: M6x1.0 (Stainless steel piston rod)
- Weight: 0.45kg (Aluminum alloy construction)
- Dimensions:
- Total Length: 136mm (at mid-stroke position)
- Height: 34mm (Mounting surface to top)
- Width: 34mm (Profile dimension)
- Mounting Spacing: 20mm (Center-to-center hole distance)
Precision multi-axis positioning cylinder featuring 360° adjustable mounting angles and micrometer-grade fine-tuning capability. The TCLJ series utilizes a unique wedge-lock mechanism for secure position retention, with IP54-rated construction for dust/drip resistance. Requires filtered air (5-50μm) with lubrication (ISO VG32 recommended).
Industrial Applications:
- PCB board clamping/fixturing systems
- Robotic end-effector position calibration
- Optical lens alignment in manufacturing
- Precision jig adjustment for automotive parts assembly
- 3D printer nozzle positioning mechanisms
Installation Best Practices:
Always perform axis alignment before locking mechanism engagement.
Use 0.5-1.0Nm torque for adjustment screws. Lubricate guide shafts monthly
with light machine oil (ISO VG15-32). Avoid side-load exceeding 5N.
| Property | Property Value |
|---|---|
| sku | TCLJ12X40-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <40mm> |
