Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X40-40S
$117.47
Regular price
$124.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X40-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Apply thread locker (medium strength) to adjustment screws after final alignment.
Perform axis calibration using dial indicator (recommended 0.01mm resolution).
Avoid side-load exceeding 15N during operation.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X40-40S 3-Axis Adjustable Cylinder Specifications
- Series: TCLJ (Triple Axis Compact Line)
- Bore size: 12mm
- Stroke: 40mm
- Rod diameter: 6mm
- Operating pressure: 0.05–0.9 MPa
- Adjustment range: ±2° angular compensation (X/Y/Z axes)
- Mounting type: Through-hole base mounting with M5×0.8 threads
- Cushioning: Rubber bumper + adjustable shock absorber
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Operating temperature: -10℃ to 70℃
- Seal material: NBR + Special polyurethane blend
- Ambient humidity: ≤95% RH (non-condensing)
- Weight: 380g ±5%
- Dimensions: 120mm(L) × 40mm(W) × 40mm(H)
- Protection class: IP54 (dust/water spray resistant)
- Lubrication: Pre-lubricated (Use ISO VG32 or equivalent)
Precision 3-axis compensator cylinder with micron-level alignment capability (±0.05mm repeatability). Features chromium-plated rod and anodized aluminum body for corrosion resistance. Integrated locking nuts enable stable position retention after adjustment. Requires 5μm filtered air with 1-10mg/m³ oil mist content.
Typical Applications:
- PCB assembly pick-and-place mechanisms
- Laser cutting head positioning systems
- Semiconductor wafer handling robots
- Precision fixture alignment in CNC machining
- Automated optical inspection (AOI) equipment
Installation note:
Apply thread locker (medium strength) to adjustment screws after final alignment.
Perform axis calibration using dial indicator (recommended 0.01mm resolution).
Avoid side-load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | TCLJ12X40-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <40mm> |
