Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X50-20S
$119.80
Regular price
$127.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X50-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Use locking compound (LOCTITE 243 recommended) on adjustment screws after alignment.
Maintain 0.5mm minimum clearance between stopper plates during stroke adjustment.
Requires dry air with 5-40μm filtration.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X50-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X50-20S
- Type: 3-axis adjustable compact cylinder (ISO 6432 compliant)
- Bore size: 12mm
- Stroke: 50mm (adjustable via stopper screws)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Mounting types: Front flange (standard), rear flange, or side mount
- Rod end: Female M5x0.8 thread (standard), male thread optional
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (nitrile rubber)
- Cushioning: Adjustable rubber buffer (both ends)
- Weight: 0.52kg ±3% (without accessories)
- Dimensions:
- Length (extended): 125mm ±1mm
- Width (body): 34mm ±0.5mm
- Height (mounting surface): 42mm ±0.5mm
- Air port size: G1/8 (ISO standard) with 4mm push-in fitting
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP mist compatible)
A precision multi-axis positioning cylinder featuring X/Y/Z axis adjustment (±2mm range) through hexagonal eccentric collars and adjustment screws. The triple-axis alignment system enables micron-level positioning accuracy (repeatability ±0.1mm) for complex alignment tasks. Includes anti-rotation guide rods and chromium-plated piston rod with wear-resistant scraper.
Typical Applications:
- PCB assembly equipment - component positioning
- Lens polishing machines - optical alignment
- Semiconductor handling - wafer stage adjustment
- Medical device assembly - micro-part positioning
- Automated inspection jigs - multi-axis calibration
Installation note:
Use locking compound (LOCTITE 243 recommended) on adjustment screws after alignment.
Maintain 0.5mm minimum clearance between stopper plates during stroke adjustment.
Requires dry air with 5-40μm filtration.
| Property | Property Value |
|---|---|
| sku | TCLJ12X50-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <50mm> |
