Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X70-10S
$123.26
Regular price
$130.76
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X70-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Operation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial use.
Avoid lateral overload beyond 15N. For fine adjustment, use 1.5mm hex key
and recalibrate every 50,000 cycles.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X70-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X70-10S
- Type: 3-axis adjustable pneumatic cylinder (self-contained guide)
- Bore size: 12mm
- Stroke: 70mm (adjustable via built-in stopper)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: Standard base mounting with 4x M3 threaded holes
- Material: Aluminum alloy body, CRMO steel piston rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40 (dust resistant)
- Weight: 0.35kg ±5%
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H)
Precision 3-axis cylinder with integrated guide rails for multi-directional position control. Features dual-axis lateral adjustment (±2mm) and vertical stroke adjustment through a hexagonal wrench. The T-slot design allows tool-free mounting of accessories. Ideal for applications requiring micron-level positioning accuracy in confined spaces.
Typical Applications:
- PCB component insertion machines
- Semiconductor wafer handling systems
- Precision optical lens alignment
- Automated test equipment positioning stages
- Pharmaceutical blister packaging units
Operation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial use.
Avoid lateral overload beyond 15N. For fine adjustment, use 1.5mm hex key
and recalibrate every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | TCLJ12X70-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 70mm |
