Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X100-40S
$145.13
Regular price
$152.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X100-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation guidance:
Use M4×12 mounting screws (recommended torque 1.2N·m). Perform axis alignment
calibration before locknut tightening. Lubricate with ISO VG32 hydraulic oil
during maintenance cycles.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X100-40S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X100-40S
- Type: Triple-axis adjustable pneumatic cylinder
- Bore size: Ø16mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (G1/8 optional)
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting style: Fixed base with multi-axis adjustment slots
- Rod material: Stainless steel (SUS304)
- Body material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU hybrid seals
- Protection rating: IP54 (standard), IP67 optional
- Weight: 980g ±2% (with standard accessories)
- Dimensions:
- Length (retracted): 225mm
- Width (base plate): 55mm
- Height (mounting surface): 32mm
- Adjustment range: ±3mm (X/Y axes), ±5° (Z-axis rotation)
Precision multi-axis cylinder with micro-adjustment capability (±0.1mm repeatability), featuring triple-axis alignment slots for XYZ-axis compensation. Integrated shock absorption system reduces vibration during high-speed operation (max 1.5m/s). Compatible with auto-switch sensors (SM/SMH series). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 standards.
Industrial Applications:
- PCB component insertion machines
- Semiconductor wafer handling systems
- Precision fixture alignment in CNC tooling
- Robotic end-effector positioning
- Optical lens assembly automation
Installation guidance:
Use M4×12 mounting screws (recommended torque 1.2N·m). Perform axis alignment
calibration before locknut tightening. Lubricate with ISO VG32 hydraulic oil
during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | TCLJ16X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 100mm |
