Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Lock adjustment screws with 0.3-0.5N·m torque after alignment.
Use shim washers when mounting on uneven surfaces. Perform axis
lubrication every 500km of cumulative travel.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X125-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X125-20S
- Type: 3-axis adjustable cylinder (ISO 6432 compliant)
- Bore size: 16mm
- Stroke: 125mm ±0.5mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Mounting type: 20mm spaced side mounting holes (M4 threads)
- Piston rod thread: M10×1.25
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Seal material: Polyurethane (NBR optional)
- Body material: Aluminum alloy (anodized finish)
- Weight: 540g ±3% (without accessories)
- Dimensions: 203mm(L) × 60mm(W) × 60mm(H)
- Repeat accuracy: ±0.2mm
- Max lateral load: 15N
- Protection rating: IP54 (standard seals)
Precision 3-axis cylinder featuring ±5° angular adjustment on X/Y/Z axes through micrometer-style dials (graduation 0.05mm). Includes anti-rotation guide and dual magnet slots for sensor mounting. Requires ISO VG32 hydraulic oil or equivalent lubrication.
Typical Applications:
- CNC machine tool clamping position fine-tuning
- Automated optical inspection (AOI) equipment alignment
- Semiconductor wafer handling robots
- Precision jig calibration systems
- 3D printing platform leveling mechanisms
Installation note:
Lock adjustment screws with 0.3-0.5N·m torque after alignment.
Use shim washers when mounting on uneven surfaces. Perform axis
lubrication every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | TCLJ16X125-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 125mm |
