Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X150-30S
$162.81
Regular price
$170.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X150-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation protocol:
Always perform axis alignment before locking the adjustment nuts.
Use torque wrench (0.4-0.6N·m) for screw adjustments. Lubricate guide rods
with ISO VG32 hydraulic oil monthly. Avoid side loads exceeding 15N.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X150-30S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X150-30S
- Type: 3-axis adjustable compact cylinder (with lock nut)
- Bore size: 16mm
- Stroke: 150mm
- Max adjustable angle: ±3° per axis (XY directions)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Mounting style: Through-hole base mounting
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Cushioning: Adjustable air cushion
- Weight: 820g ±2%
- Dimensions:
- Length: 196mm (full extension)
- Width: 45mm (main body)
- Height: 45mm (main body)
- Mounting base: 62mm × 25mm
Precision multi-axis alignment cylinder featuring micrometer-style adjustment screws (0.5mm per rotation) for fine positional calibration. The triple-axis design allows compensation for parallel offset and angular misalignment up to ±0.5mm in X/Y directions. Integrated locking mechanism maintains position stability under vibration. Requires ISO 8573-1:2010 Class 3 compressed air.
Typical Applications:
- PCB assembly positioning systems
- Laser cutting/focusing stage alignment
- Precision fixture adjustment in automotive jigs
- Semiconductor wafer handling robots
- Optical lens centering mechanisms
Installation protocol:
Always perform axis alignment before locking the adjustment nuts.
Use torque wrench (0.4-0.6N·m) for screw adjustments. Lubricate guide rods
with ISO VG32 hydraulic oil monthly. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TCLJ16X150-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 150mm |
