Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X20-10S
$110.02
Regular price
$117.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X20-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Operation tip:
Lock adjustment screws with 0.3-0.5Nm torque after alignment.
Perform axis calibration in sequence: Z-axis first → Y-axis → X-axis.
Maximum lateral load: 2.5N at full extension.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X20-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X20-10S
- Type: Triple-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke: 20mm (±10mm adjustable range)
- Operating pressure: 0.05–0.9 MPa
- Port thread: M5×0.8 (standard), G1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated stainless steel
- Buffer type: Adjustable rubber cushion
- Mounting style: Front flange with 4×M4 threaded holes
- Position detection: Magnet embeddable (sensor not included)
- Temperature range: -10℃ to 70℃
- Weight: 580g ±2%
- Dimensions (L×W×H): 98mm (total length) × 40mm (flange width) × 40mm (height) *Excluding adjustment screws
- Accessory kit: Includes 2x hex wrench (1.5mm/2mm), 4x M4×8 mounting screws
Precision multi-axis positioning cylinder featuring micron-level adjustment capability through three orthogonal axes (X/Y/Z). The TCLJ series incorporates a unique anti-rotation mechanism with 0.01mm graduations on adjustment screws. Sealed with high-grade NBR for oil mist lubrication compatibility. Requires filtered air (≤50μm particles).
Industrial Applications:
- PCB assembly line alignment systems
- Lens polishing machine position calibration
- Semiconductor wafer handling robots
- Medical device testing jigs
- Automotive sensor calibration stations
Operation tip:
Lock adjustment screws with 0.3-0.5Nm torque after alignment.
Perform axis calibration in sequence: Z-axis first → Y-axis → X-axis.
Maximum lateral load: 2.5N at full extension.
Lubrication:
Initial lubrication pre-installed. Relubricate every 500km stroke travel
using ISO VG32 turbine oil. Avoid silicone-based greases.
| Property | Property Value |
|---|---|
| sku | TCLJ16X20-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
